Rockfon® Color-all™

Rockfon® Color-All™ acoustical ceiling tiles are available in multiple ceiling colors and is made from stone wool and has high acoustic absorption, and fire performance.

Budget

$ $ $ $ $

Back
  • Order Sample
34 exclusive colors organized in 6 themes
Smooth surface
Excellent sound absorption (NRC = 0.85-0.90)
High fire performance
Optimal design freedom due to the variety of edges (lay-in, tegular and concealed) and colors

Recommended Applications

Office

Meeting Room
Reception
Lunchroom
Corridor

Education

Auditorium
Library
Music Room
Corridor
Cafeteria

Leisure

Auditorium / Concert Hall
Cinema
Fitness Centre / Locker Room
Museum
Restaurant / Pub / Nightclub
Stadium
Hotel
Cafe/Restaurant

Retail

Boutiques
Convention Centre
Department Store
Shopping Centre
Showroom
Supermarket

Healthcare

Cafeteria
Reception
Corridor

Back
  • Order Sample

Noise Reduce Coefficient (NRC)

Edge Thickness (ft/in) Min suspension height (in) αw NRC Class (ISO) Sound curve
CDX 7/8"
Sound curve
SL 3/4"
Sound curve
SLN 3/4"
Sound curve
SQ 5/8"
Sound curve

Sound absorption is measured in accordance with ISO 354.

Sound absorption data αp, αw and absorption class are calculated in accordance with ISO 11654. Sound absorption properties of islands and baffles are quantified by the equivalent sound absorption area Aeq expressed as m² per item.

Back
Sound curve
Back
Sound curve
Back
Sound curve
Back
Sound curve

Product Specifications

Compare
Ceiling Attenuation Class (CAC) Ceiling Attenuation Class (CAC) 22
Room-to-room sound insulation is measured in accordance with ASTM E1414. The measured value is reported as a Ceiling Attenuation Class (CAC).
Articulation Class (AC) -
Speech privacy is measured in accordance with ASTM E1111. The measured value is reported as Articulation Class (AC).
Fire Performance Fire Performance
UL723 (ASTM E84) Flame Spread Index: 5
Smoke Developed Index (UL Labeled): 0
CAN/ULC S102 Flame Spread Index: 15
Smoke Developed Index: 5
Fire Class A
Light Reflection Light Reflection Light reflection: 0
Light reflection expressed in % is measured in accordance with ASTM E1477.
Humidity And Sag Resistance Humidity And Sag Resistance Up to 100% RH
Rockfon ceiling tiles are dimensionally stable even at humidity levels of up to 100% relative humidity and can be installed at all temperatures ranging from 32 °F to 104 °F. They can be installed during the very early stage of the build (when windows are not fully sealed). Their lightweight yet stable non-hygroscopic character minimizes the final weight of the fully-installed ceiling.

*Rockfon® stone wool ceiling panels are dimensionally stable at up to 100% relative humidity.
Cleaning Cleaning Vacuum
Vacuum: The surface can be vacuum cleaned with a soft brush attachment.
Hygiene Hygiene Stone wool provides no sustenance to microorganisms
VOC Emissions All Rockfon stone wool acoustic solutions are GREENGUARD Gold low VOC certified and meet the State of California’s Department of Public Health Services Standard Practice for Specification Section 01350 (California Section 01350) for testing chemical emissions.

Selected potential applications: LEED, WELL, CHPS, Green Globes, BREEAM Int. and CALGreen.
Environment Environment Fully recyclable
Thermal Insulation Thermal Insulation R Value (BTU Units): 2.2 - 3.1
RSI Value (Watts Units): 0.39 - 0.54
The thermal resistance of Rockfon products is measured in accordance with ASTM C518 and expressed in R-Value (hr.ft2.F/Btu) and RSI Value (m2k/W).
Material Stone wool (Mineral Wool) ceiling tiles with factory painted glass scrim surface
ASTM E1264 Classification Type XX - Stone wool base with membrane-faced overlay, Pattern G
Warranty Warranty 30-Year Limited Product Warranty. See www.rockfon.com
Low VOC for NA Yes
Back
Room-to-room sound insulation is measured in accordance with ASTM E1414. The measured value is reported as a Ceiling Attenuation Class (CAC).
Back
Speech privacy is measured in accordance with ASTM E1111. The measured value is reported as Articulation Class (AC).
Back
Back
Back
Light reflection expressed in % is measured in accordance with ASTM E1477.
Back
Rockfon ceiling tiles are dimensionally stable even at humidity levels of up to 100% relative humidity and can be installed at all temperatures ranging from 32 °F to 104 °F. They can be installed during the very early stage of the build (when windows are not fully sealed). Their lightweight yet stable non-hygroscopic character minimizes the final weight of the fully-installed ceiling.

*Rockfon® stone wool ceiling panels are dimensionally stable at up to 100% relative humidity.
Back
Vacuum: The surface can be vacuum cleaned with a soft brush attachment.
Back
Back
Back
Back
The thermal resistance of Rockfon products is measured in accordance with ASTM C518 and expressed in R-Value (hr.ft2.F/Btu) and RSI Value (m2k/W).
Back
Back
Back
Back

Colors

  • Citytones
    • Stone
      Stone Color Code: NCS S 1500-N Light reflection: 0.55
    • Mastic
      Mastic Color Code: NCS S 3500-N Light reflection: 0.33
    • Tarmac
      Tarmac Color Code: NCS S 6005-R20B Light reflection: 0.13
    • Plaster
      Plaster Color Code: NCS S 1005-R80B Light reflection: 0.58
    • Zinc
      Zinc Color Code: NCS S 4005-R50B Light reflection: 0.33
    • Anthracite
      Anthracite Color Code: NCS S 7010-R90B Light reflection: 0.07
    • Gravel
      Gravel Color Code: NCS S 3502-B Light reflection: 0.34
    • Concrete
      Concrete Color Code: NCS S 6500-N Light reflection: 0.16
    • Charcoal
      Charcoal Color Code: NCS S 9000-N Light reflection: 0.04
  • Natural tones
    • Stucco
      Stucco Color Code: NCS S 0505-Y40R Light reflection: 0.7
    • Hemp
      Hemp Color Code: NCS S 3005 Y20R Light reflection: 0.45
    • Clay
      Clay Color Code: NCS S 4502 Y Light reflection: 0.22
    • Chalk
      Chalk Color Code: NCS S 2005 Y40R Light reflection: 0.51
    • Cork
      Cork Color Code: NCS S 4010 Y30R Light reflection: 0.3
    • Humus
      Humus Color Code: NCS S 8010 Y70R Light reflection: 0.05
    • Linen
      Linen Color Code: NCS S 4005 Y50R Light reflection: 0.29
    • Earth
      Earth Color Code: NCS S 5010 Y50R Light reflection: 0.22
  • Sensorial tones
    • Light
      Light Color Code: NCS S 0510 Y10R Light reflection: 0.71
    • Fresh
      Fresh Color Code: NCS S 2005 B20G Light reflection: 0.51
    • Misty
      Misty Color Code: NCS S 1010 R40B Light reflection: 0.6
    • Sunrise
      Sunrise Color Code: NCS S 0510 Y50R Light reflection: 0.65
    • Breeze
      Breeze Color Code: NCS S 1030 R80B Light reflection: 0.45
    • Twilight
      Twilight Color Code: NCS S 3010 R20B Light reflection: 0.29
    • Aqua
      Aqua Color Code: NCS S 1550 R80B Light reflection: 0.25
  • Energetic tones
    • Chili
      Chili Color Code: NCS S 1580 Y90R Light reflection: 0.12
    • Curacao
      Curacao Color Code: NCS S 2555 B20G Light reflection: 0.22
    • Vitamin
      Vitamin Color Code: NCS S 0585 Y20R Light reflection: 0.46
  • Precious tones
    • Copper
      Copper Light reflection: 0.34
    • Gold
      Gold Light reflection: 0.41
    • Mercury
      Mercury Light reflection: 0.44
  • Sophisticated tones
    • Garnet
      Garnet Color Code: NCS S 5030 Y90R Light reflection: 0.12
    • Ermine
      Ermine Color Code: NCS S 5030 B Light reflection: 0.12
    • Scarlet
      Scarlet Color Code: NCS S 5040 Y90R Light reflection: 0.08
    • Emerald
      Emerald Color Code: NCS S 6030 B30G Light reflection: 0.07
Back
  • Order Sample

Configure your product

This product has 8 variants in different sizes.

01 Edge

02 Size

03 Summary

SQ

product image
product image
product image
product image
product image
product image
product image
product image
product image
product image
product image

Square lay in drop ceiling tiles are a cost-effective solution that provide easy access to the plenum area. They are compatible with both 15/16" and 9/16" acoustical suspension systems and are easily demountable.

illustration
Lay-in grid
Tegular grid
Concealed grid
Select length and width (in)
Select thickness (in)
Edge
Dimensions
Thickness

Full range

Edge Dimensions (ft/in) Thickness (ft/in) Weight (lbs/ft2) Recommended installation system
CDX 2' x 2' 7/8" 0.75

Noise Reduce Coefficient (NRC)

NRC 0.95
CAC 22

Tile details

Packaging

Pieces Per Package 10
Area Per Pack 40.00 ft2
CDX 4' x 2' 7/8" 0.75

Noise Reduce Coefficient (NRC)

NRC 0.95
CAC 22

Tile details

Packaging

Pieces Per Package
Area Per Pack 80.00 ft2
SL 2' x 2' 3/4" 0.69

Noise Reduce Coefficient (NRC)

NRC 0.95
CAC 22

Tile details

Packaging

Pieces Per Package
Area Per Pack 40.00 ft2
SL 4' x 2' 3/4" 0.69

Noise Reduce Coefficient (NRC)

NRC 0.95
CAC 22

Tile details

Packaging

Pieces Per Package
Area Per Pack 80.00 ft2
SLN 2' x 2' 3/4" 0.69

Noise Reduce Coefficient (NRC)

NRC 0.95
CAC 22

Tile details

Packaging

Pieces Per Package
Area Per Pack 40.00 ft2
SLN 4' x 2' 3/4" 0.69

Noise Reduce Coefficient (NRC)

NRC 0.95
CAC 22

Tile details

Packaging

Pieces Per Package
Area Per Pack 80.00 ft2
SQ 2' x 2' 5/8" 0.47

Noise Reduce Coefficient (NRC)

NRC 0.85

Tile details

Packaging

Pieces Per Package 28
Area Per Pack 112.00 ft2
SQ 4' x 2' 5/8" 0.47

Noise Reduce Coefficient (NRC)

NRC 0.85

Tile details

Packaging

Pieces Per Package 28
Area Per Pack 112.00 ft2
Back

Noise Reduce Coefficient (NRC)

αw 22
NRC 0.95
Class
Sound curve
sound curve

Tile details

Minimum installation height "
Easy access -

Packaging

Pieces Per Package 10
Area Per Pack m2
Back

Noise Reduce Coefficient (NRC)

αw 22
NRC 0.95
Class
Sound curve
sound curve

Tile details

Minimum installation height "
Easy access -

Packaging

Pieces Per Package
Area Per Pack m2
Back

Noise Reduce Coefficient (NRC)

αw 22
NRC 0.95
Class
Sound curve
sound curve

Tile details

Minimum installation height "
Easy access -

Packaging

Pieces Per Package
Area Per Pack m2
Back

Noise Reduce Coefficient (NRC)

αw 22
NRC 0.95
Class
Sound curve
sound curve

Tile details

Minimum installation height "
Easy access -

Packaging

Pieces Per Package
Area Per Pack m2
Back

Noise Reduce Coefficient (NRC)

αw 22
NRC 0.95
Class
Sound curve
sound curve

Tile details

Minimum installation height "
Easy access -

Packaging

Pieces Per Package
Area Per Pack m2
Back

Noise Reduce Coefficient (NRC)

αw 22
NRC 0.95
Class
Sound curve
sound curve

Tile details

Minimum installation height "
Easy access -

Packaging

Pieces Per Package
Area Per Pack m2
Back

Noise Reduce Coefficient (NRC)

NRC 0.85
Class
Sound curve
sound curve

Tile details

Minimum installation height "
Easy access -

Packaging

Pieces Per Package 28
Area Per Pack m2
Back

Noise Reduce Coefficient (NRC)

NRC 0.85
Class
Sound curve
sound curve

Tile details

Minimum installation height "
Easy access -

Packaging

Pieces Per Package 28
Area Per Pack m2
Back
